The stereomicroscopes of the SZM series are instruments specifically designed for laboratory and industry applications.
 Their optical and mechanical qualities place
them at the top of that sought-after category
of appliances and the price/quality ratio is exceptionally good. Sharing the same optical system consisting of binocular and trinocular heads with zoom objectives, the four models
of the SZM series find their proper application wherever professional instruments are required at a particularly contained
cost.
The numerous accessories provide an ample choice of possible configurations and extend the flexible use of the instruments.
SZM-1
Binocular Stereozoom Microscope
SZM-2
Trinocular Stereozoom Microscope
SZM-3
Binocular Stereozoom Microscope, with overhanging stand
SZM-4
Trinocular Stereozoom Microscope, with overhanging stand
Stereomicroscopes distributed by INGEO - SZM series
Heads
Binoculars and trinoculars 360° rotating and 45° inclinated.
Interpupillary distance
Adjustable between 51 and 75 mm.
Dioptric compensation
On both eyepiece tubes (bino & trino).
Eyepieces
EWF10x/20 mm
Objectives
Parafocal achromatic zoom 0,7x...4,5x (6,428:1 zoom factor).
Specimen stage
Models with illumination are fitted with a black/white disc for contrast, specimen clamps and a frosted glass disc for transmitted light.
Focusing
By means of a rack and pinion controlled by a pair of knobs placed on both sides.
Microscope stand
Pillar stand 30 mm and 25 cm high, base 26x20x6h cm.
Overhanging stand 42 cm high, 23x23 cm base and 45 cm horizontal arm lenght.
Illumination
Double adjustable illuminator for incident and transmitted light fitted with two 12V/15W halogen bulbs. 230V/50Hz power supply. The angle of the incident illumination is adjustable.
For further informations about Stereomicroscopes, please contact Eng. Luigi Paracchini, phone number +39 0321 921654 (during office hours), or send an email to info@ingeosnc.it
|
